grinderMain Applications
This machine is mainly used for weak electrical substances and high temperature resistant substances such as chemical industry, medicine (traditional Chinese medicine), food, spices, resin powder, coating powder, etc.
grinderMain Features
This machine uses a wind wheel type high-speed rotating knife and a fixed knife for impact, shearing and grinding. It not only has a good crushing effect, but also generates a strong airflow in the cavity during crushing, which allows the heat in the crushing chamber and the finished product to flow out of the screen together. The crushing fineness can be determined by the screen.
model | 20B | 30B | 40B |
Production capacity (kg/h) | 60-150 | 100-300 | 160-800 |
Spindle speed (r/min) | 5800 | 4500 | 3800 |
Feed size (mm) | 6 | 10 | 12 |
Grinding fineness (mesh) | 60-150 | 60-120 | 60-120 |
Motor power (kw) | 4 | 5.5 | 11 |
Fan power (kw) | 1.5 | 1.5 | 1.5 |
Overall dimensions (mm) | 1100*600-1650 | 1200*650*1650 | 1350*700*1700 |
Medicinal Material Crusher – Efficient Herbal Processing Solution
The Medicinal Material Crusher is a high-performance industrial machine designed for grinding and crushing herbs, roots, and other medicinal raw materials. It is widely used in the pharmaceutical, herbal medicine, and food industries, providing uniform particle size, enhanced production efficiency, and reliable operation.
Engineered with durable components, energy-efficient motors, and safety features, this crusher ensures consistent powder quality while minimizing maintenance downtime. Its user-friendly design makes it suitable for both small-scale and industrial production lines.
High Efficiency and Throughput
Capable of crushing large volumes of medicinal materials quickly.
Reduces processing time and improves overall production efficiency.
Adjustable Particle Size
Precision control over output fineness, suitable for various formulations.
Ensures uniform powder quality for tablets, capsules, or herbal extracts.
Durable Construction
Made from high-strength stainless steel and alloy components.
Resistant to corrosion, wear, and heavy-duty operation.
Energy Saving Design
Optimized rotor and motor design for lower energy consumption.
Reduces operational costs over long-term use.
Safety and Ease of Use
Protective covers and emergency stop switches.
Easy to assemble, disassemble, and clean without specialized tools.
Versatile Applications
Suitable for roots, stems, leaves, seeds, and other herbal materials.
Compatible with both dry and slightly moist materials.
| Model | Motor Power (kW) | Capacity (kg/h) | Feeding Size (mm) | Output Size (mm) | Material |
|---|---|---|---|---|---|
| MMC-200 | 7.5 | 200–500 | ≤50 | 1–5 | Stainless Steel |
| MMC-300 | 11 | 500–1,200 | ≤60 | 1–6 | Stainless Steel |
| MMC-400 | 15 | 1,200–2,500 | ≤80 | 1–8 | Stainless Steel |
| MMC-500 | 22 | 2,500–4,000 | ≤100 | 1–10 | Stainless Steel |
Note: Custom configurations are available depending on raw material characteristics and production requirements.
The Medicinal Material Crusher is widely applied in:
Pharmaceutical Industry – Grinding herbal powders for tablets, capsules, and extracts.
Herbal Medicine Production – Processing roots, leaves, and seeds into uniform powder.
Food Industry – Crushing herbs for teas, supplements, and nutraceuticals.
Cosmetic Industry – Preparing herbal ingredients for creams and lotions.
Each crusher undergoes rigorous performance testing to ensure reliability and efficiency:
Throughput Test – Measures material processing speed and output consistency.
Durability Test – Checks wear resistance and component longevity.
Safety Compliance Test – Verifies emergency stop functions, protective covers, and overload protection.
Energy Efficiency Test – Confirms optimized power consumption during operation.
Proper maintenance ensures long service life and consistent performance.
Inspect feeding and crushing chambers for material buildup.
Check motor and electrical connections for proper operation.
Ensure all safety features are functional.
Clean filters, screens, and discharge chutes.
Lubricate moving parts according to manufacturer instructions.
Inspect blades, hammers, or rotor components for wear.
Check alignment and tension of belts or chains.
Tighten bolts and fasteners on the structural frame.
Replace worn bearings or blades as needed.
Comprehensive inspection of motors, electrical systems, and crushing components.
Upgrade or replace critical components to maintain peak performance.
| Issue | Possible Cause | Recommended Solution |
|---|---|---|
| Reduced Crushing Efficiency | Worn blades or clogged chamber | Replace blades; clean chamber thoroughly |
| Motor Overheating | Overload or poor ventilation | Reduce load; inspect motor cooling system |
| Excessive Noise or Vibration | Loose bolts or misalignment | Tighten fasteners; realign rotor components |
| Material Sticking in Chamber | High moisture content | Pre-dry materials; clean chamber regularly |
The manufacturer provides full technical support, including:
Installation Assistance – Guidance on proper setup and calibration.
Operational Training – Instruction for safe and efficient operation.
Spare Parts Supply – Access to genuine replacement parts for extended machine life.
Remote Troubleshooting – Online guidance for resolving operational issues quickly.
Standard Packaging – Protective crates with cushioning for long-distance transport.
Custom Packaging – Available based on shipment volume and destination.
Shipping Conditions – Keep the machine dry and avoid exposure to heavy moisture during transport.
High Efficiency – Rapid crushing and uniform powder quality.
Durable & Reliable – Long-lasting components built for heavy-duty applications.
Energy Saving – Optimized motor and rotor design reduce energy consumption.
Versatile & User-Friendly – Suitable for a wide range of herbal materials and easy to operate.
Comprehensive Support – Manufacturer provides maintenance guidance, spare parts, and technical support.
The Medicinal Material Crusher is a critical tool for herbal and pharmaceutical processing, offering high efficiency, durability, and consistent output quality. Its robust design, safety features, and adjustable particle size make it ideal for industrial-scale operations. With regular maintenance, proper handling, and technical support, this crusher ensures long-term reliability and optimal performance, meeting the needs of modern medicinal material processing.
